| Optical data | Typical Value | Remarks |
| Light source | White LED / 415 nm LED / 540 nm LED / 785nm LD | |
| CCT of white light | 5500±500K | White LED after 1m, NA0.62,Φ5mm optical fiber |
| CRI of whith light | ≥90 | White LED after 1m, NA0.62,Φ5mm optical fiber |
| Luminous flux of white light | 2300 lm | Output after module |
| Output power of 415nm | 1800 mW | Output after module |
| Output luminous flux of of 540nm | 280 lm | Output after module |
| Output power of 785nm | 3500 mW | Output after module |
| Back focal length | 25.6 mm | From the last lens vertex |
| Working mode | ||
| 4 single color light output | White light /415nm/ 540nm/785nm | |
| 7 compound light output | White light +415nm/ white light+785nm/415nm+540nm/415nm+785nm/ 540nm+785nm/415nm+540nm+785nm/white light+415nm+785nm | |
| Electrical data | ||
| Input voltage | DC 12V | Can be customized according to customer requirement |
| Power consumption | 90 W | Driver board consumption included |
| Dimming mode | RS 232 | 5%~100% |
Illuminance distribution on the focal plane for white light
|
